Model Description


DESIGN. INSTANT CLASSIC


Designed for top performance, with improvements to the chassis, electronics and engine. A dual seat with a new improved-comfort design and a simple, lightweight sub-frame represent the latest technical innovations, for an even better riding experience. Not to mention a design that has always refused to compromise.

FEEL THE POWER OF SOUND

RR means power and torque: with 140 HP and 86 Nm, fun is guaranteed. Improvements to distribution have also allowed a reduction in friction. Also new is the increased-efficiency exhaust system, while the injectors have been redesigned to guarantee better fuel atomisation.

Model Specification


  • Engine

    Type

    Three cylinder, 4 stroke, 12 valve

    Engine

    Timing

    “D.O.H.C” with mechanical chain tensioner

    Displacement (cc)

    798 cm3 (48.68 cu. in.)

    Compression Ratio

    13.3:1

    Starting

    Electric

    Max Power

    103 kW (140 hp) at 12.300 r.p.m.

    Max Torque

    87 Nm (8.87 kgm) at 10.100 r.p.m.

    Engine Management

    Integrated ignition

  • Dimensions

    Bore x Stroke

    79 mm x 54.3 mm (3.1 in. x 2.1 in.)

    Wheelbase

    1400 mm (55,12 in.)

    Length

    2045 mm (80,51 in.)

    Width

    875 mm (34,45 in.)

    SeatHeight

    830 mm (32,68 in.)

    Ground Clearance

    135 mm (5,31 in.)

    Trail

    103.5 mm mm (4.07 in.)

    Dry Weight

    175 kg (385,80 lbs.)

  • Performance

    Cooling

    Cooling with separeted liquid and oil radiators.

    Clutch

    Multi-disk wet clutch with hydraulic actuation and back torque limiting device

    Max Speed

    244.0 km/h (151.6 mph)

  • Transmission

    Gearbox

    Primary Drive

    22/41

  • Frame

    Tank Capacity

    16.5 l (4.36 U.S. gal.)

    Frame Type

    ALS Steel tubular trellis

    Rear Swing Arm

    Aluminium alloy

  • Suspension

    Front Suspension

    Marzocchi “UPSIDE DOWN” aluminium telescopic hydraulic fork with DLC treatment , with anodized fork legs and having rebound-compression damping and spring preload external and separate adjustment

    Rear Suspension

    Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment

  • Brakes

    Front Brakes

    Double floating disc with Ø 320 mm (Ø 12.6 in.) diameter, with steel braking disc and flange

    Rear Brakes

    Single steel disc with Ø 220 mm (Ø 8.66 in.) dia

  • Wheels

    Front Wheels

    Aluminium alloy 3.50 ” x 17 ”

    Rear Wheels

    Aluminium alloy 5.50 ” x 17 ”

    Front Tyres

    120/70 - ZR 17 M/C (58 W)

    Rear Tyres

    180/55 - ZR 17 M/C (73 W)
