Model Description


DESIGN. EVERY DETAIL COUNTS


The hallmark of the Rosso Range is, of course, its distinctive colouring: red, the ultimate racing colour, provides the crowning glory to its design. The differences from the standard set-up are subtle, like the surface milling on the profile of the wheel spokes, for example.

FEEL THE POWER OF SOUND

The in-line three-cylinder engine deriving from the F3 800 excels in terms of its performance, output range, weight and record-breaking measurements. With 110 HP and a torque of 83 Nm, the bike’s full potential can be unleashed instantly and easily, on every type of track.

Model Specification


  • Engine

    Type

    Three cylinder, 4 stroke, 12 valve

    Engine

    Timing

    “D.O.H.C” with mechanical chain tensioner and DLC tappet

    Displacement (cc)

    798 cm3 (48.68 cu. in.)

    Compression Ratio

    12.3:1

    Starting

    Electric

    Max Power

    82 kW (112 hp) at 11.000 r.p.m.****

    Max Torque

    85 Nm (8.67 kgm) at 8.500 r.p.m.

    Engine Management

    Integrated ignition

  • Dimensions

    Bore x Stroke

    79 mm x 54.3 mm (3.1 in. x 2.1 in.)

    Wheelbase

    1400 mm (55,12 in.)

    Length

    2045 mm (80.51 in.)

    Width

    875 mm (34.45 in.)

    SeatHeight

    830 mm (32.68 in.)

    Ground Clearance

    135 mm (5.31 in.)

    Trail

    103,5 mm (4.07 in.)

    Dry Weight

    175 kg (385,8 lbs.)

  • Performance

    Cooling

    Cooling with separeted liquid and oil radiators

    Clutch

    Multi-disk wet clutch with hydraulic actuation and back torque limiting device

    Max Speed

    237.0 km/h (147.2 mph)

  • Transmission

    Gearbox

    Primary Drive

    22/41

  • Frame

    Tank Capacity

    16.5 l (4.36 U.S. gal.)

    Frame Type

    ALS Steel tubular trellis

    Rear Swing Arm

    Aluminium alloy

  • Suspension

    Front Suspension

    Marzocchi “UPSIDE DOWN” telescopic hydraulic fork with rebound-compression damping and spring preload external and separate adjustment

    Rear Suspension

    Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment

  • Brakes

    Front Brakes

    Double floating disc with Ø 320 mm (Ø 12.6 in.) diameter, with steel braking disc and flange

    Rear Brakes

    Single steel disc with Ø 220 mm (Ø 8.66 in.) dia.

  • Wheels

    Front Wheels

    Aluminium alloy 3.50 ” x 17 ”

    Rear Wheels

    Aluminium alloy 5.50 ” x 17 ”

    Front Tyres

    120/70 - ZR 17 M/C (58 W)

    Rear Tyres

    180/55 - ZR 17 M/C (73 W)
