Model Description


The entry level for really ambitious racers. The state-of-the-art, water-cooled DOHC engine delivers 11 kW (15 hp), 12 Nm of torque and total race performance for everyday use. Every ride turns into preparation for the next race with the new street-legal KTM RC 125.

Stay ahead of the competition with the KTM RC 125’s state-of-theart, liquid-cooled, single-cylinder engine with double overhead camshafts (DOHC) that provide a crisp throttle response, thanks to electronic fuel injection. The stylish sweet-sounding muffler meets EURO 4 standards.

Quick, agile and playful handling is assured on the streets or racetrack courtesy of the same 66.5 degree steering-head angle as found as a feature of its bigger brothers. In fact, the KTM RC 125 shares the same winning potential as the rest of the RC range. WP suspension components complete the package.

The KTM RC 125 has a comfortable big-bike feel with freedom of body movement for both rider and pillion. Clip-on handlebars and easily accessible switches offer advanced control, while a 10-litre fuel capacity allows hours of non-stop cornering fun.

The KTM RC 125’s clean but aggressive bodywork provides a unique supersport look that stands out from the pack. Its aerodynamic advantage helps gain greater lean in turns.

A highly sophisticated electronics system has been integrated into the KTM RC 125, offering riders a range of high-end technical features that ensures that the bike performs to its full potential in all riding conditions. Smooth power, total control.

Ride the city streets and open roads with individuality by modifying your KTM RC 125 to suit your preference and style using the KTM PowerParts range. It boasts a wide variety of accessory options across KTM’s Street motorcycle range. All KTM PowerParts are developed alongside their chosen machine, meaning that KTM riders only get parts that perfectly complement their ride and provide that important ‘factory fit’ straight from the dealer.

Model Specification


  • Engine

    Engine Type

    1-cylinder, 4-stroke engine

    Displacement

    125 cc

    Starter

    Electric starter

    Transmission

    6 speed

    Engine Lubrication

    Wet sump

    Cooling

    Liquid cooled

    Clutch

    Wet multi-disc clutch, mechanically operated

    Ignition

    Bosch EMS

    ABS System

    Bosch 9MB Two Channel

    Bore x Stroke

    Compression Ratio

    Final Drive

  • Dimensions

    Bore

    58 mm

    Stroke

    47.2 mm

    Wheelbase

    Ground Clearance (unloaded)

    178.5 mm

    Seat Height

    820 mm

    Weight (No Fuel)

    139 kg

  • Performance

    Performance

    11 kW (15 hp)

    Primary Gear Ratio

    Secondary Gear Ratio

    Brake System Front

    Four piston, radially bolted caliper, brake disc 300 mm

    Brake System Rear

    Single piston, floating caliper, brake disc 230 mm

  • Frame

    Frame

    Steel trellis frame, powder coated

    Chain

    520 X-Ring

    Steering Head Angle

    66.5 degrees

    Tank Capacity

    9.5 litres

    Suspension Travel Front/Rear

    Brakes: Front/Rear

    Rims: Front/Rear

    Tank Capactiy

    Ground Clearence (Unloaded)

  • Suspension

    Front Suspension

    WP USD 43 mm

    Rear Suspension

    WP Monoshock

    Suspension Travel Front

    120 mm

    Suspension Travel Rear

    150 mm
