Model Description


The KTM 790 DUKE is devastatingly accurate. The agility you’d expect from a single, blended with the meaty punch of a twin. It carves corners with pinpoint precision, boasting the all-new 799 cc LC8c parallel twin motor nestled into one of the lightest and most compact chassis around. The KTM 790 DUKE is all about being fast where it counts – in the corners. Dynamically flicking from one bend to the next, putting you in the heart of the action and not on the sidelines.

At the dark core of the KTM 790 DUKE, lurks a compact 799 cc parallel-twin powerplant, just waiting to tear up a mountain pass or a short circuit. Boasting exceptional efficiency with class-leading power and torque, this new engine is a lightweight force to be reckoned with.

A large dose of the KTM 790 DUKE’s agility comes from the deftness of its lightweight chassis. While it uses its compact parallel twin engine as a structural and dynamic pivot point for quick responsiveness – it is the tubular steel frame, innovative cast aluminum subframe and swing arm that conspire with performance-oriented wheels, brakes and WP suspension to unleash a ride unlike any DUKE before it.

Designed to deliver confidence-inspiring control for a wide range of potential riders, the KTM 790 DUKE’s sleek body offers the ease-of-movement needed to effortlessly direct The Scalpel’s dynamic movements out on the ride, while still allowing fine adjustability for comfort – whatever your skill level.

The hunkered-down aggressive stance of the KTM 790 DUKE is intimidating to all who cross its path. It clearly takes some of its design cues from the KTM 1290 SUPER DUKE R – most obvious being the unique headlight ‘face-mask’. Its distinctive sharp lines and compact 11/13 proportions are set off by signature KTM graphics, which leave no doubt as to its road-dominating intentions.

The KTM 790 DUKE might carry some muscle and grit, but it also comes with some serious brainpower as standard. Delivery of the 78 kW (105 hp) and 87 Nm is efficiently controlled by advanced electronics and next-generation rider aids. Even when you’re flirting with the limit, KTM’s combination of the most advanced software and electronics in the world of motorcycling allow you to easily select the level and degree of assistance needed to maximize your thrill factor out on any ride. All you have to do is focus on the road ahead – and hold on tight.

You’ll find a full range of KTM PowerParts and luggage options available for the KTM 790 DUKE. Make aesthetic changes to intensify your ride, to reflect your personal attitude, fine-tune the function and adjust the performance to perfectly match your individual riding style. Wherever you ride and however you like to attack the turns, KTM PowerParts have you covered!

Model Specification


  • Engine

    Engine Type

    2-cylinder, 4-stroke parallel twin

    Displacement

    799 cc

    Starter

    Electric starter

    Transmission

    6-speed

    Engine Lubrication

    Pressure lubrication with 2 oil pumps

    Cooling

    Liquid cooling

    Clutch

    PASC™ slipper clutch / mechanically operated

    Ignition

    Bosch EMS with RBW

    ABS System

    Bosch 9.1 MP two-channel ABS (incl. Supermoto mode, disengagable)

    Bore x Stroke

    Compression Ratio

    Final Drive

  • Dimensions

    Bore

    88 mm

    Stroke

    65.7 mm

    Wheelbase

    Ground Clearance (unloaded)

    186 mm

    Seat Height

    825 mm

    Weight (No Fuel)

    169 kg

  • Performance

    Performance

    77 kW (105 hp)

    Primary Gear Ratio

    Secondary Gear Ratio

    Brake System Front

    Four piston, radially fixed caliper with 300 mm brake disc

    Brake System Rear

    Two piston caliper with 240 mm brake disc

  • Frame

    Frame

    Tubular steel trellis frame, powder coated

    Chain

    520 X-Ring

    Steering Head Angle

    66 degrees

    Tank Capacity

    14 litres

    Suspension Travel Front/Rear

    Brakes: Front/Rear

    Rims: Front/Rear

    Tank Capactiy

    Ground Clearence (Unloaded)

  • Suspension

    Front Suspension

    WP USD 43mm fork

    Rear Suspension

    WP shock absorber with preload adjuster

    Suspension Travel Front

    140 mm

    Suspension Travel Rear

    150 mm
