Model Description


Ride from home and feel the adrenaline build while chasing tarmac curves towards your favourite offroad location. No trailer required just twist the throttle of the all-new KTM 690 ENDURO R, which really comes into its own when the dirt begins and the trail gets more extreme. Its new chassis, revised styling, and an updated version of the trusted 690 LC4 motor, are enhanced by upgraded electronics and new WP XPLOR suspension. Master more challenging terrain on this lightweight, high-performance king of versatility.

The engine combines powerful acceleration from the very lowest revs with an outstanding free-revving nature and refined engine running. Another big plus; it’s extremely economical with fuel.


The trellis frame is manufactured from lightweight sections of top-quality chrome-molybdenum steel tubing of varying thicknesses. This type of balanced frame design provides high torsional rigidity for best handling and rideability, while a more specifically-tuned longitudinal flexibility can absorb the wheel impact energy, supporting the suspension for reduced rider fatigue.

The new dashboard provides the rider with additional information, for 2021 the rider will have the added benefit of seeing his/her current selected gear as well as RPM displayed in clear view of the display.

Model Specification


  • Engine

    Engine Type

    1-cylinder, 4-stroke

    Displacement

    693 cc

    Starter

    Electric starter

    Transmission

    6-speed

    Clutch

    APTC slipper clutch, hydraulically actuated

    ABS System

    Bosch 9.1 MP (incl. Cornering-ABS and offroad mode, disengageable)

    Engine Management System

    Keihin EMS with RBW, twin ignition

  • Dimensions

    Bore

    105 mm

    Stroke

    80 mm

    Ground Clearance (unloaded)

    269 mm

    Seat Height

    929 mm

    Weight (No Fuel)

    146 kg

  • Frame

    Frame

    Chrome-moly tubular space frame, powder-coated

    Chain

    X-Ring 5/8 x 1/4

    Steering Head Angle

    62 degrees

    Tank Capacity

    13.5 litres

  • Suspension

    Front Suspension

    WP XPLOR-USD 48 mm

    Rear Suspension

    WP XPLOR with Pro-Lever linkage

    Suspension Travel Front

    250 mm

    Suspension Travel Rear

    250 mm

  • Performance

    Brake System Front

    Brembo twin-piston floating calliper, brake disc

    Brake System Rear

    Brembo single-piston floating calliper

    Power

    74 hp

    Torque

    73.5 Nm

  • Brakes

    Front Brake Disc Diameter

    300 mm

    Rear Brake Disc Diameter

    240 mm
