Pick a point on a map, drop a pin, and hit the road. The KTM 1290 SUPER ADVENTURE R is engineered to cross the wildest, most challenging terrain with unmatched ability and class-leading performance. It leaves us saying only one thing – Uncharted territory beware! The KTM 1290 SUPER ADVENTURE R is primed and ready to plant its flag anywhere on the planet.
With a sledgehammer hit of 160 hp and a massive 138 Nm of earth-twisting torque, the proven V-twin LC8 engine once again takes the accolades as the most compact, lightest, and best performing engine in the segment. Its greener too, meeting all EURO5 regulations and will deliver 15.000 km service intervals and low fuel consumption, trip after trip, mile after mile.
Helping the KTM 1290 SUPER ADVENTURE R shift – in more ways than one – is a 6-speed PANKL transmission with a new, lighter aluminum shifting drum with optimized tracks for faster, smoother gear changes. Shifting forks have also been coated in copper to reduce wear and tear. This also helps the Quickshifter+ engage quicker for ultra-fast, slick gear changes.
PASC SLIPPER CLUTCH
Not only does the slipper clutch open when the engine back-torque becomes too high, it also assists when you open up the throttle. The former prevents destabilizing rear wheel chatter when braking sharply or decelerating; the latter reduces the lever force required for changing gears, allowing the clutch to be controlled with one trigger happy finger – saving you energy while riding.
Providing the bark for the bite, the KTM 1290 SUPER ADVENTURE R features a completely reworked exhaust system. Two new headers lead the exhaust gas to a hydroformed collector chamber with two catalytic converters. These, in conjunction with 3 lambda sensors allow the emissions to stay within the latest EURO 5 limits. Meanwhile, at the business end, a newly designed stainless-steel silencer provides a typically v-twin tone.
Thanks to a reworked airbox, riders can now easily access the air filter by simply removing 4 screws to remove the storage compartment ahead of the fuel filler cap. Also, the filter itself now features vertical ribs, instead of horizontal. Which helps direct dust or sand towards the bottom of the air box, without getting sucked into the filter slats. Overall, a better design for hardcore adventurers.
The KTM 1290 SUPER ADVENTURE R now features 2 separate radiators instead of a one-piece unit. The result is better heat dissipation, and improved cooling all-round. Cleverly designed air ducts now also stream cool air towards the engine, not only keeping the motorcycle cool, but the rider’s legs cool too.
A new, reworked, and lightweight, chrome-molybdenum stainless steel trellis frame featuring laser-cut tubes, combines with forged elements for an ultra-strong component on the KTM 1290 SUPER ADVENTURE R. The steering head has been moved 15 mm rearwards, to shorten the overall frame for improved cornering behavior, while the front engine mount has been rotated forward by 2 degrees to aid in hard acceleration, keeping the front end firmly planted on the ground.
Extended by 15 mm to optimize tracking stability in conjunction with the shorter frame, the die-cast, open-lattice swingarm retained it’s lightweight and pin-point manufacturing to provide stiffness and uncompromised control when hitting the dirt.
Serious offroad exploration demands hardcore equipment. The spoked wheels of the KTM 1290 SUPER ADVENTURE R feature new and robust aluminum rims made for KTM by ALPINA, with an improved sealing system to make them 100% tubeless. What’s more, is that instead of the typical rubber band sealing the rim to prevent air from leaking through the nipples, the wheels have an O-ring seal on each nipple.
The KTM 1290 SUPER ADVENTURE R is fitted with high-performance WP XPLOR suspension which was co-developed with test rider Quinn Cody at the helm. A WP XPLOR fork with 48 mm inner tubes takes care of business at the front and has been derived from the successful KTM off-road models, and features split fork technology and all-new settings for even better offroad performance. At the rear, is a high-end PDS monoshock, which is fully adjustable in spring preload with an external handwheel, rebound, and compression including high and low-speed compression damping.
Heading off the beaten track often leads to encountering some pretty rough roads. Thankfully, things are kept in check by a WP steering damper as standard. Linked between the frame and the triple clamp, the steering damper ensures things are kept tidy when the road isn’t.
A completely redesigned 23 litre, 3-part fuel tank. This is made up of two large fuel cells on each side of the frame, with an upper, central vessel that supplies fuel to the lateral units. The fuel cap is also new and electronically controlled. But the best bit? A storage compartment reminiscent of the iconic KTM 990 ADVENTURE has been included in the new design, complete with a USB socket and big enough to hold your cellphone, sunglasses or wallet.
Illuminated switches don’t only look good, but make sense when you’re out in low light conditions and need to locate the important buttons in the blink of an eye.
Where you’ll be spending most of your time, the all-new seat on the KTM 1290 SUPER ADVENTURE R is designed to guarantee maximum comfort, thanks to high-quality foam padding. This one-piece, stepped seat sits 880 mm off the deck and allows for seamless rider movement when traversing difficult terrain. Accessing the under-seat area is also made easier, with the seat latch released at the push of a button.
Taking charge at the helm is an all-new scratch-resistant 7-inch TFT display. Unmatched in terms of graphics and readability, adventurers can access information on the fly, quickly and easily without navigating complex menus. This comes thanks to a 6-way switch cube on the handlebar and the new quick select and favorites buttons. Connectivity is also taken care of by way of KTM MY RIDE, which connects via Bluetooth for turn-by-turn navigation, music, and even answering calls. Still catching glare? The TFT screen is tilt-angle adjustable.
USB PHONE POCKET
No bar-mounted cellphone cradle? No problem. A convenient compartment keeps your smartphone safe on the road. It keeps it charged too, thanks to its integrated USB socket. The optional incoming call and audio functions link the phone to the TFT via Bluetooth, so less time is spend staring at the screen, and more time is spent looking ahead.
